600 * 600mm 48W Rechargeable Led Light Panel 3700LM CRI80 Isolated
Driver UL SAA
Features
1. Energy Saving. Saving 55%-70% electricity cost to traditional
Panels.
2. Advanced super longlife and stable driver.
3. Professional thermal management.
4. Instant on, no warm up time required.
5. No noise, no flickering.
6. No UV or IR radiation in the beam, mercury free.
7. Anti-shock, anti-moisture.
8. Aluminum alloy 6063 body and leading light transmitting Optical
PMMA cover.
9. Exquisite small appearance. Easy to install with mounting
brackets.
10. Eco-friendly. No mercury and other harmful materials
11. No delay on start.
12. Long life span, longer than 50,000H
Rechargeable Led Light Panel spec
Part No. | ZLRP6004048WSRE |
Optics Parameters
| Light Source | 288pcs SMD2835 EPISTAR |
Luminous Flux(lm) | 3600-3800LM |
CCT(K) | warmwhtie(3000K)/white(6000K)/ Neturalwhite4000K |
CRI(Ra) | more than 80Ra |
Beam Angle | 120 degree |
Light Attenuation ratio (%) | less than 3% in 30,000Hrs |
Lifespan (Hrs) | more than 50,000Hrs |
Electric Parameters | Input Voltage(V) | 85-265Vac |
Frequency(Hz) | 50/60 Hz |
Input Current(mA) | 950mA (@ 220 Vac ) |
Total Power(W) | 48W |
Power Factor | 0.95 |
Turn-on Time(S) | less than 0.05 S (@ 220Vac) |
Dielectric Voltage Withstand Test | 3750Vac/1min |
Structure Parameters | Material | Aluminum+ PMMA |
Size(mm) | 600x600x40mm |
Net Weight(g) | 4.7KG |
Water Proof(IP) | Indoor Use Only IP44 |
Integrated Parameters | Operating Temperature | -40 ~ +55 Centigrade |
Storage Humidity | 0% ~ 95%R.H. |
Dimmable | Optional |
About the Driver
Driver used Isolated Constant Current Driver with PF>0.95,
THD<15%, CE/RoHS approval
3-Year warranty.
IES Test result
Product Application
1:Hotels, Conference, Meeting rooms
2:Factories & Offices
3:Commercial Purposes
4:Residential/institution Buildings
5:Schools, Colleges & Universities, Hospitals
6:Other lighting use
